| Number 1 Brand in the world |
| UNICOS is the first developed company for Auto Chart Projector in Korea and has the highest technology and accumulated production experience which was already proved by world wide market. |
| |
| Clear and precise projection chart |
| Four different types of chart shows clear and bright images for your right vision test |
| |
| Comforatable operation |
| A remote controller and fast chart change make operator comfortable and stable |
| Outstanding Features |
| |
– The first development with the highest technology and accumulated production Experience
– Clear & precise projection chart
– Attractive design
– Comfortable operation by remote control and fast chart change
– Various and flexible chart type |
|
| Specification |
| |
| Chart |
31 pcs |
| Selection Speed |
Average 0.3 sec |
| Mask |
1 Open, 3 Vertical, 3 Horizontal, 21 Single Letters |
| Filter |
Red/Green |
| Proj. Distance |
2.0 ~ 7.0 m (3m is standard) |
| Proj. Magnification |
30 X (at 5m) |
| Proj. Size |
ø 252 mm and 330(W) X 225(H) (at 5m) |
| Tilt Angle |
Ball Joint (±10°) |
| Lamp |
6V 20W Halogen Lamp |
| Power Supply |
AC 100 ~ 240V, 50/60 Hz |
| Power Consumption |
80 VA |
| Auto-Off Function |
5 ~ 10 minutes after |
| Dimension/Weight |
Body : 265(H)X230(W)X360(D) / 6.0 Kg |
| |
Remote Controller : 20(H)X64(W)X195(D)mm/180g |
| Interface |
8 pin Connector for Control of chart, mask and R/G filter by a Digitalized Refractor’s controller |
| Accessories |
Dust Cover, Polarized Metal Screen, Polarized Glass, Spare Fuse(2), Batteries(2), Spare Lamp(1) |
|
|
